Department of Electrical and Electronics Engineering
S. No. View of the Laboratory Name of the Laboratory Major Equipment / Facilities Available in the Laboratory
Laboratory sessions conducted as per the scheme of curriculum
Odd Semesters Even Semesters

1.
fac1

Basic Electrical Engineering Laboratory

1--Phase Transformers,
1--Phase Auto-transformers,
3--Phase Auto-transformers,

Resistive loads and rheostats,

Audio Frequency oscillators and

Regulated Power supplies.

B.Tech., I Sem
CSE, IT, ME, CSN, CSO











B.Tech, II-Sem EEE, ECE, CE, ECI, CSM









2.
fac1

Networks Laboratory

Standard Network Theorem kits.
Function Generators and Regulated Power Supplies.

1-Phase Transformers

3-Phase and 1- Phase Autotransformers

Cathode Ray Oscilloscopes

Desktop Computers - 5 Nos

B.Tech. III Sem

3.
fac1

Electrical Measurements Laboratory

DC Crompton's Potentio Meter

AC and DC Bridges,

Instrument Transformers,

1-Phase Energy Meter,

Linear Variable Differential Transformer,
Phase Shifting Transformer,
Thermocouple Kit,
Strain Gauge Kit

URR-18 B.Tech, III Sem





---

4.
fac1

Electrical Machines Laboratory

Motor-Generator sets(DC  & AC),
3-Phase Synchronous Machines,
3-Phase and 1-Phase Induction Motors,

DC Series and Compound Motors,
3-Phase Rectifier

3-Phase and 3 -Winding Transformer,

Scott Connected Transformers

B.Tech., V Sem, B.Tech., VII Sem

B.Tech. IV Sem

5.
fac1

Control Systems Laboratory

Linear System Simulator and Second Order System Study Unit, Stepper Motor Control Using Microprocessor, Second Order System Study Unit, LAG-Lead Network Study Unit,

Speed Torque, DC Motor Study Unit, Closed Loop Speed Control of 3-Phase Induction Motor-ACS,  Characteristics of DC and AC Servo Motors, DSO 70 MHz Bandwidth, DC Position Control System, Personal Computers(Core i3 Processor/8 GB RAM/1 TB HDD), 6 KVA UPS

---

B.Tech., VI Sem,

6.
fac1

Power Electronics Laboratory

Three Phase Controlled Rectifier,

Cathode Ray Oscilloscope & Digital Storage Oscilloscope,
1- Phase Dual Converter & 1- Phase Cyclo converter, 3-Phase Inverter,
1- Phase AC Voltage Controller,
3-Phase & 1-Phase Isolation Transformers,

1-Phase Power Analyzer,

Personal Computers-10 (core i3 Processor 8GB RAM/ 1TB memory), 6 KVA UPS

B.Tech, V Sem, EEE

---

7.
fac1

Electric Drives Laboratory

Speed measurement and Closed Loop Control using PMDC Motor,

3-Phase/1-Phase Input Thyristorised Drive 1 Hp DC Motor with Closed Loop Control,

Cyclo Converter based AC Induction Motor Control Equipment,
Speed Control of 3-Phase wound Rotor Induction Motor, 1-Phase PWM inverter,

DSP based DC/AC Drive, Stepper Motor Control, BLDC Motor with Controller,

Three Phase Input IGBT, 4 Quadrant Chopper Drive for DC Motor Units with Closed Loop Control, TMS320F28335 Experimental Kit, Intelligent Power Module, Permanent Magnet Synchronous motor – Exterior Type Permanent Magnet Synchronous Motor – Interior Mount type, Speed Control of Switched Reluctance Motor.

---

B.Tech VI Sem, EEE

M.Tech.,(PE)

II Sem



8.
fac1

Digital Simulation Laboratory

36 Desktop Computers(Core i3 processor/8GB RAM/ 1TB memory),
Software(MATLAB, PSCAD, PSIM, MiPower),

LCD Projector,

10 KVA UPS,

Printer

B.Tech, VII Sem,





----

9.

fac1

Power Systems Laboratory

Artificial Transmission Line,
Percentage Differential Relay,
Static Over Current Relay,
DC Network analyzer
Transformer Oil Testing Kit,
1- Phase Transformers and 3-Phase Transformer,
Tap Changing Transformer,
3-Phase Alternator Coupled to DC Shunt Motor

B.Tech, VII Sem,

----

10.
fac1

Renewable Energy Systems Laboratory

Solar PV Training and Research System (SPVTR),

15 Desktop Computers(Core i5 processor/8GB RAM/ 1TB HDD),

6 KVA UPS

M.Tech I Sem-PE,

----

11.
fac1

Power Converters Laboratory

MOSFET & IGBT Device,

Buck-Boost converter ,
Push- Pull Isolated DC-DC Converter,

3 – Phase PWM Inverter ,

1 – Phase Semi – Controlled PWM Rectifier,

1 – Phase Full – Controlled PWM Rectifier,

Digital Storage Oscilloscope

M.Tech. I Sem, PE Lab

----

12.
fac1

Power Electronic Simulation Laboratory

21 Desktop Computers(Core i5 processor/8GB RAM/ 1TB HDD),

MATLAB 2021B
LCD Projector,
6 KVA UPS,

Printer



----

M.Tech.(PE), II Sem,
